Assistina One: With 1 x Quick RM & 1 x Quick ISO Adaptor
Assistina One: With 1 x Quick RM & 1 x Quick ISO Adaptor
Fast, thorough and easy to use: Assistina One speeds up daily operations and facilitates dental handpiece care. With the shortest cycle time in its class and its high-quality care results, the innovative maintenance solution is a top dental device – designed for top dental professionals.
Assistina One is the first choice for maintaining dental transmission instruments, including handpieces, air motors and air scalers. The new generation of the W&H single-port device is equipped with the exceptional Quick Connect System for switching between handpieces. It can be easily adapted to individual needs and fits perfectly into every workflow.
The entire lubrication and spray channel cleaning process only takes 18 seconds, making the Assistina One the fastest maintenance solution in its class. It only works with compressed air; no electric power supply is needed.
The unit is set up and ready to go in no time at all. Together with the one-touch start button and convenient cartridge management for refilling oil and cleaning liquids, the Assistina One is a modern maintenance solution for dental practices with high standards in handpiece care.
High-quality transmission instruments require high-quality care.
In fact, proper and professional maintenance plays an essential role in the longevity and value retention of handpieces. The maintenance unit ensures perfect care and performs the correct lubrication cycles crucial for the function and long service life of dental handpieces.
The Assistina One thoroughly lubricates all gear parts, cleans the spray channels properly and even dries the inner parts with compressed air.
Technical Data
- Process: Cleaning the spray channels, lubrication
- Suitable for: Straight and contra-angle handpieces, turbine handpieces, air scalers, air motors
- Air consumption: approx. 50 Nl/min.
- Operating pressure: 5–10 bar (controlled via an integrated, automatic pressure controller)
- Dimensions (W × D × H): 166 × 383 × 243 mm
- Weight: 2.2 kg
- Capacity: 200 ml W&H Activefluid cleaning solution, 200 ml W&H Service Oil F1
Adaptor Overview
Select the handpiece type:
- Straight and contra-angle handpieces: require Quick ISO adaptor
- Turbine handpieces: require Quick RM adaptor
- Brand specific connection: Alternative adaptors are also available
Contents
- Assistina One Unit
- Air connection hose (2m)
- One Care Set
- Quick RM adaptor
- Quick ISO adaptor
